L angel bead corner bead corner protector L trim forming machine

  • L angel bead corner bead corner protector L trim forming machine
  • L angel bead corner bead corner protector L trim forming machine
  • L angel bead corner bead corner protector L trim forming machine
  • L angel bead corner bead corner protector L trim forming machine

L angel bead corner bead corner protector L trim forming machine

    Payment Type: L/C,T/T
    Min. Order: 1 Set/Sets
    Delivery Time: 30 Days
    Packaging: 20 ft container
    Productivity: 25-50m/min
    Brand: Zhongtuo
    Transportation: Ocean,Land
    Place of Origin: China(mainland)
    Supply Ability: 30 sets per month.
    Certificate: CE/ISO9001

Basic Info

Model No.: ZT-009

Product Description

L angel bead Corner Bead Corner Protector L trim forming machine

Zhongtuo is mainly making the corner beads forming machine of roll formed shapes: Angles rollformer, Channels rollformer, Cee Sections rollformer, Hat Sections rollfomer, and Z Sections rollformer. Additionally, we produce Custom Roll Formed Tubes rollfomer. Be assured that our engineers have your solution, even if it is not directly featured. such as : hat furring z furring Fast Cap & ArchwayWall Fast Cap for 2?" Metal Studs?" R. Bullnose Fast Cap & ArchwayBumper Bead System,J Trim ,L Trim,corner bead tile trim,metal L trim ,shadow line corner bead for suspended ceiling system,corner bead inside corner bead corner bead for tile

Wall Angle Roll Forming Machine is a strip of raw materials, through continuous cold rolling molding, production of complex cross-section profiles, which consists of decoiler, guide rack, forming hosts, calibration device, cut-off part, receiving station , composed of electrical control and so on.

Wall Angle Roll Forming Machine Technological process:

Uncoiler-feeding system-roll forming machine-cutting system-table

Wall Angle Roll Forming Machine Uncoiler system:
Usage:It is used to support the steel coil and uncoil it in a turnable way. Passive uncoil pulled by roll forming system.
Loading capacity:1500kg
Uncoiling width:300mm

Inner diameter: 450-550 mm

keel roll forming machine 2

Wall Angle Roll Forming Machine Main Roll Forming System:
Usage: In order to keep the product shape and precision, adopts welded sheet structure, motor reducer drive, chain transmission ,roller was chromed which can keep the molding plate surface smooth and not easy to be marked when it is being stamped.
Length of the main part: about 3000 х800 х1400
Weight of main part: 3000kg
Voltage : 380 V/50HZ 3Phase or as your required
Roller fixer : middle plate
Frame : 450 H steel welded
Drive mode: gear
Material of rollers:GCr12MoV, surface hard chromium plating.
Material of shafts: 45# steel with tempering
Diameter of shafts: φ 40mm

Number of rollers : 10 rollers

Main power: 3 kw


Wall Angle Roll Forming Machine Shearing Mechanism:
Function : Automatic cutting controlled by PLC
It adopts the hydraulic drive and automatic location to decide the dimension and cut the target products.
Material of blades: Cr12 quenched
Power supply : hydraulic power

Components:It contains one set of blade , one hydraulic tank and one cutter machine.

7

Wall Angle Roll Forming Machine Hydraulic Station:
It is controlled by gear pump. After filling the hydraulic oil into the hydraulic oil tank ,the pump drive the cutter machine to begin the cutting job.
Power: 5.5 kw

Hydraulic oil: 46 #


Wall Angle Roll Forming Machine Electric Control System:

1. Adopted PLC , frequency converter , Delta touch screen from Taiwan to ensure high speed with stability, precision and lifetime.
2. Other electric element are Panasonic
keel roll forming machine 4

Wall Angle Roll Forming Machine Warranty:

1. We will provide technical support for the whole life.

2. Installation & adjustment : We can take a vedio for the customer and the customer can also come to our factory, we can train customer how to installation and adjustmentthe machine.

3. Oversea service: the buyer should charge of visa, return ticket, food and accommodation overseas and USD50/person/day salary.
